Product Details:
|
| Max Load: | 20KN | Resolution: | 1/250000 |
|---|---|---|---|
| Effective Force Range: | 0.4％～100％ (0.5grade) | Load Cell: | Basic Configuration：one Piece( Max Load) |
| Effective Test Width: | 390mm (can Be Enlarge As Customer Request) | Traveled Stroke: | 800mm( Without Grip) |
| Test Standard: | ASTM D412, ASTM D638, ISO37 Etc | Accuracy: | 0.5grade |
| Weight: | 350 KG With Package | Dimension: | 85*75*210cm |
| Model: | HZ-1003A | ||
| High Light: | 20KN UTM Tensile Testing Machine,0.5 Grade UTM Tensile Testing Machine,Computer Servo Type Universal Testing Machine |
||
| Model | HZ-1003A |
| Max load | 20KN |
| Accuracy | 0.5grade |
| Effective force range | 0.4％～100％ (0.5grade) |
| Resolution | 1/200000 |
| Effective test width | 390mm (can be enlarge as customer request) |
| Effective Tensile stroke | 800mm (can be enlarge as client request) |
| Test speed | 0.01～500mm/min |
| Power | 0.4KW |
| Weight | About 300 Kg |
High-precision electronic motor can be set to five-speed, the components are connected by plug-way, Floor-standing models, it is taken account of modern industrial design and ergonomics in modeling and coating. Tensile Testing Machine can be tested all the materials in stretch, compression, bending, shear, embedded relay, peeling, tearing, crack, etc, such as rubber, plastics, leather, metal, nylon wire, fabric, paper, aerospace, packaging, construction, petrochemical, electrical, vehicle, etc.
HZ-1003A Computer Type Bending Testing Machine.pdf...
