Product Details:
|
Number Of P: | 2 3 5 6 6 8 9 10 P | Power: | Three-phase380V/~/50Hz |
---|---|---|---|
Temperature Setting Range And Control Accuracy: | 18~25℃±1℃ | Humidity Setting Range And Control Accuracy: | 45~65%±5% |
Refrigerant: | R410A | Evaporator: | Copper Tube Finned |
Model: | L125TH L150TH L150TH2 L200TH L225TH L250TH | Items: | Cabinet Type (combined) Frequency Conversion Constant Temperature And Humidity |
Highlight: | 18C Factory Air Conditioner,R410A Factory Air Conditioner,25C Frequency Conversion Air Conditioner |
Cabinet Type Frequency Conversion Factory Air Conditioner 2,3,5, 6, 8, 9, 10 P Temperature Setting Range 18~25℃±1℃
Factory Air Conditioner s used for indoor air conditioning under various environmental conditions, and has multiple functions such as cooling, dehumidification, heating, humidification, and ventilation. Temperature control range: when the temperature is set at 18-25°C, the control accuracy is ±0.5-1°C, the relative humidity is set at 50-70%, and the control accuracy is ±5-10%.
Factory Air Conditioner Application
The unit has a variety of models to choose from, and can be widely used in the air conditioning needs of electronic factories, hospitals, pharmaceutical factories, printing factories, post and telecommunications, banks, computer rooms, power supply and distribution stations, communication stations and other buildings.
Technical Parameters
items | cabinet type (combined) frequency conversion constant temperature and humidity | ||||||||
Model | Indoor Unit | L125TH | L150TH | L150TH2 | L200TH | L225TH | L250TH | ||
outdoor unit | TK-125WB | TK-150WB | TK-150WB | TK200WB | TK225WB | TK250WB | |||
number of p | P | 5 | 6 | 6 | 8 | 9 | 10 | ||
Cooling capacity | kW | 12.5 | 15 | 15 | 20 | 22.5 | 25 | ||
Electric heating | kW | 23.4 | 28 | 28 | 36 | 41 | 47 | ||
indoor unit | air volume | m3 / h | 2500 | 3600 | 3500 | 5000 | 5000 | 5400 | |
Temperature setting range and control accuracy | 18~25℃±1℃ | ||||||||
Humidity setting range and control accuracy | 45~65%±5% | ||||||||
power | 220V/~/50Hz | Three-phase380V/~/50Hz | |||||||
Refrigerant | R410A | ||||||||
Evaporator | Copper tube finned | ||||||||
throttling mode | Electronic expansion valve | ||||||||
wind machine | Type | Cross flow centrifugal fan | |||||||
Power | kW | 0.16 | 0.18 | 0.16 | 0.22 | 0.24 | 0.26 | ||
heater | Type | PTC electric heater | |||||||
Power | kW | 8 | 11 | 11 | 14 | 16 | 18 | ||
Humidifier | Type | PTC electric heater |
Factory Air Conditioner Dehumidification principle:
Heating: start the heater, when the air flows through the heater, the air is heated and the temperature rises.
Humidification: Start the humidifier, and the water vapor generated by the humidifier is continuously sent into the room by the fan to achieve the purpose of humidification..
Factory Air Conditioner Cooling principle:
When the refrigeration system is working, the high-temperature and high-pressure R410 gas discharged from the compressor enters the condenser and is condensed into a medium-temperature supercooled liquid.
