Product Details:
Place of Origin: China
Brand Name: lixian
Certification: CE
Model Number: HZ-2018
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: wood
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: negotiate

OEM Aging Environmental Testing Machine Rustproof Multipurpose

Description
Inside Size: 500*500*600mm Temprature Range: RT+10~+70°C, 0-+70℃
Meet Standards: JIS K 6259 ASTM1149 ASTM1171 Ozone Produced Mode: Ozone Generator Or UV Absorption Method
Ozone Concentration: 0~1000pphm Adjustable Inside Air Velocity: Over 2 Feet/sec
Air Flow: A.0-6 Cfm;B. 10-20 Cfh Nside Size: 500*500*600mm
Accessories: Tensile Fixture 6 Groups Warranty: 1 Year
Customized Support: OEM, ODM Place Of Origin: China
High Light:

OEM Environmental Testing Machine

,

Rustproof Environmental Testing Machine

,

Multipurpose Aging Test Chamber

JIS K 6259 ASTM1149 ASTM1171 ISO1431 DIN53509 Lab Ozone Aging Test Chamber Ozone-Resistance Test Chamber



Ozone Test Chamber is a major factor in rubber cracking although it is rare in the atmosphere, ozone aging tank simulates and enhance the condition of ozone in the atmosphere to study the effects of ozone on rubber, and then identify and evaluate the method to resist ozone and aging for rubber, adopt effective anti-aging measures to enhance the life of rubber products.



Main feature:

Equipment by the occurrence of silent and efficient ozone generator ozone gas, and a certain amount of air processed, the switch in the mixture into the chamber, the continuous line UV detector to detect the concentration of ozone, according to the occurrence of effective control of ozone to the ozone chamber to maintain the appropriate concentration of work by heating humidification systems to meet all the test conditions.



Main function:

Ozone Test Chamber is used to test the ozone environment, the characteristics of crack-resistant rubber, ozone resistance testing machine, can control and adjust the concentration of ozone environment, to determine the anti-ozone properties of the specimen.



Corresponding standard:

JIS K 6259 ASTM1149 ASTM1171 ISO1431 DIN53509 GB7762 GB/T13642

Technical parameter:





Model HZ-2018 Ozone Test Chamber
Ozone concentration 5~1000pphm adjustable
Relative humidity 60%RH above
Temperature RT+10+100°C
Degree of ozone concentration fluctuation 10%
Inside size 500×500×600mm
Air flow A.0-6 cfmB. 10-20 cfh
Weight 250kg
Power 1, AC220V, 15A
