ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester

ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester
ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester

Large Image :  ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester

Product Details:
Place of Origin: China
Brand Name: lixian
Certification: CE
Model Number: HZ-1007E
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: wood
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester

Description
Model: HZ-1007E Accuracy: 1grade / 0.5 Grade
Weight: About 160 Kg Maximum Load: 50N, 100N, 200N, 500N, 1KN (optional )
Effective Tensile Space: 300mm Measuring Accuracy:: The Value ±1% / The Value ±0.5%
Power Supply: 220V 50Hz Certification: CE/ISO/ASTM/ROSH
High Light:

ASTM F904 Tensile Test Equipment

,

ASTM F88 Tensile Test Equipment

,

ASTM F88 Tensile Strength Tester

Effective Tensile Space 300mm Label Peel Bond Strength Tensile Testing Machine Hz-1007e



Equipment summary:
It is a new material testing machine that combined with the electronic technology and mechanical transmission, it has accurate load speed, range of force measurement, it is mainly applied to test non-metallic and metallic material which the load is less than 1KN, it has the parameters, such as tensile strength, bending strength, compressive strength, elastic modulus, rate of elongation, yield strength and others..


Main Function
This Series machine can be applied to test lots of materials in tensile,compression, tear, Adhesive Tape peel ( 90 degrees and 180 degrees) and other small mechanical test(within 1KN).

Corresponding standard:
GB/T 16491, GB/T 1040, GB/T 8808, ASTM D3759, ASTM D3330, ASTM D882, ASTM F88, ASTM F904, ISO 37, JIS P8113.

Technical parameters:
Model Number
HZ-1007E
Accurate grade
1grade/0.5 grade
Material testing machine Maximum load
1KN
Effective measuring range
0.2%~100%/0.4%~100%
Measuring accuracy
the value ±1%/ the value ±0.5%
Tester resolution
Max load 1/200000, constant the resolution
Effective tensile stroke
300mm
Range of testing speed
0.01~500mm/min (special can be 0.01-1000mm/min)

①. Single test, 10-point statistics manually and automatically calculate its average and break values;
②. Multi-unit automatically exchange such as kgf, Lbf, N, ton
③. Function of free to take point;


ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester 0
ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester 1
ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester 2
ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester 3



UTM Fixture
ASTM F88 ASTM F904 Tensile Test Equipment Tensile Strength Tester 4
Tensile machine grips is an indispensable part of the universal test machine. Different materials need different fixture, is also a significant factor whether the test can be carried out smoothly and the accuracy of the test results. Tension testing machine fixture is an indispensable part of electronic tension testing machine. Through the fixture clamping sample for the specimen after force, the size of the test force that the fixture can bear is a very significant index of the fixture. It determines the size of the fixture structure and the size of the labor intensity of the fixture operation. Tensile testing machine fixture in the structure of no fixed mode, according to different samples and test force size, in the structure of a great difference. The company provides tensile machine grips custom services to customers around the world and export UTM for 23 year.
