Cabinet Type Frequency Conversion Factory Air Conditioner 2 3 5 6 8 9 10P 18-25C±1C

Cabinet Type Frequency Conversion Factory Air Conditioner 2 3 5 6 8 9 10P 18-25C±1C
Cabinet Type Frequency Conversion Factory Air Conditioner 2 3 5 6 8 9 10P 18-25C±1C

Large Image :  Cabinet Type Frequency Conversion Factory Air Conditioner 2 3 5 6 8 9 10P 18-25C±1C

Product Details:
Place of Origin: China
Brand Name: Taikang
Certification: CE
Model Number: Model L125TH L150TH L150TH2 L200TH L225TH L250TH
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: wood
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: negotiate

Cabinet Type Frequency Conversion Factory Air Conditioner 2 3 5 6 8 9 10P 18-25C±1C

Description
Number Of P: 2 3 5 6 6 8 9 10 P Items: Cabinet Type (combined) Frequency Conversion Constant Temperature And Humidity
Power: Three-phase380V/~/50Hz Temperature Setting Range And Control Accuracy: 18~25℃±1℃
Humidity Setting Range And Control Accuracy: 45~65%±5% Refrigerant: R410A
Evaporator: Copper Tube Finned Model: L125TH L150TH L150TH2 L200TH L225TH L250TH
High Light:

Pharmaceutical Factory Air Conditioner

,

Frequency Conversion Air Conditioner 380V

,

R410A Cabinet Type Air Conditioner

Cabinet Type Frequency Conversion Factory Air Conditioner 2,3,5, 6, 8, 9, 10 P Temperature Setting Range 18~25℃±1℃



Factory Air Conditioner s used for indoor air conditioning under various environmental conditions, and has multiple functions such as cooling, dehumidification, heating, humidification, and ventilation. Temperature control range: when the temperature is set at 18-25°C, the control accuracy is ±0.5-1°C, the relative humidity is set at 50-70%, and the control accuracy is ±5-10%.



Factory Air Conditioner Application

The unit has a variety of models to choose from, and can be widely used in the air conditioning needs of electronic factories, hospitals, pharmaceutical factories, printing factories, post and telecommunications, banks, computer rooms, power supply and distribution stations, communication stations and other buildings.



Technical Parameters



items cabinet type (combined) frequency conversion constant temperature and humidity
Model Indoor Unit L125TH L150TH L150TH2 L200TH L225TH L250TH
  outdoor unit TK-125WB TK-150WB TK-150WB TK200WB TK225WB TK250WB
number of p P 5 6 6 8 9 10
Cooling capacity kW 12.5 15 15 20 22.5 25
Electric heating kW 23.4 28 28 36 41 47
indoor unit air volume m3 / h 2500 3600 3500 5000 5000 5400
Temperature setting range and control accuracy 18~25℃±1℃
Humidity setting range and control accuracy 45~65%±5%
power 220V/~/50Hz Three-phase380V/~/50Hz
Refrigerant R410A
Evaporator Copper tube finned
throttling mode Electronic expansion valve
wind machine Type Cross flow centrifugal fan
  Power kW 0.16 0.18 0.16 0.22 0.24 0.26
heater Type PTC electric heater
  Power kW 8 11 11 14 16 18
Humidifier Type PTC electric heater
  Power kW 2.5 3 3 4 4 4.5
  Humidification capacity kg/h 2.8 3.4 3.4 4.5 4.5 5
  Inlet pipe diameter - DN15
Maximum input power kW 8.5 11



Factory Air Conditioner Cooling principle:

When the refrigeration system is working, the high-temperature and high-pressure R410 gas discharged from the compressor enters the condenser and is condensed into a medium-temperature supercooled liquid.



Factory Air Conditioner Dehumidification principle:

Heating: start the heater, when the air flows through the heater, the air is heated and the temperature rises.

Humidification: Start the humidifier, and the water vapor generated by the humidifier is continuously sent into the room by the fan to achieve the purpose of humidification..
