Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test

Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test
Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test
Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test

Large Image :  Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test

Product Details:
Place of Origin: China
Brand Name: lixian
Certification: CE
Model Number: HZ-2008
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: wood
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: negotiate

Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test

Description
Temprature Range: From 50 °C To 75 °C Testing Room Capacity: 137 * 53 * 136cm
Certification: CE/ASTM/ISO Material: Stainless Steel
Application: Industry,Auto Part Dimensions: Customized Sizes
Product Name: Rustproof Accelerated Weathering Chamber , Multifunctional Xenon Arc Test Chamber Service: Customized Service
Standard: GB ASTM AISI DIN BS,DIN,BS,ASTM,ISO Color: Customer Required
High Light:

Programmable UV Light Test Chamber

,

Rustproof UV Light Test Chamber

,

Xenon Arc Environmental Testing Machine

Uv Light Test Chamber For Programmable Lamp Laboratory Plastic Paint Rubber Test Temprature Range From 50 °C To 75 °C

UV Test Chamber

​Uv Accelerated Weathering Aging Test Chamber can simulate the ultraviolet ray in the sun, rain and dew to damage the material, QUV using UV lamp simulate the effect ultraviolet ray of sunlight, cold rain and dew.

Accelerated weathering test methods simulate extreme weather conditions using special environmental chambers and instruments that accelerate the aging process. Environmental influences can cause discoloration, cracking, corrosion and deterioration of the product inside and out.

UV Test Chamber Corresponding Standard
Accord with ASTMG53-77, GB, GJB, MIL, ASTM, CNS, IEC, JIS, AATCC, DIN, Fed Test, BS, SAE



UV Test Chamber  Main Functions
The materials are tested for several days or weeks, you can know the damage types include: bleaching, discoloration,
loss of light, powder, crack, turbidity, bubble-based, embrittlement, strength decline and oxidation.


UV Test Chamber Technical Parameter:

Model HZ-2008 UV aging test chamber
Lamps Quantity UV Lamp 8pcs, spare lamp: 4pcs, (ATLAS, UVA340, UVB313, UVC351)
Recorder Option
Radiometer Option
UV Temperature From 45 °C to 70 °C
Black temperature From 40 °C to 60 °C
Testing Capacity and sample size 48 piece (75 x 150mm) / 50 piece (75 x 150mm)
Water and Consumption Distilled water, 8 liters / day
Dimension (W x D x H) 137 x 53 x 136cm
Weight 136kg
Power 1 ψ, 120V/60Hz, 16A or 230V/50Hz, 9A, 1800W (max)
1. UV Lamp Type

UVA-340 lamp tube: UVA-340 lamp tube can well simulate the short-wave ultraviolet rays in sunlight, that is, the sunlight whose cut-off wavelength is 365nm to 295nm.
UVB-313 lamps: UVB-313 lamps generally emit short-wave ultraviolet rays that are stronger than the sun's ultraviolet radiation on the earth's surface, which can accelerate material aging to the greatest extent.
UVA-351 lamp: simulates the ultraviolet sunlight through the window, which is the most effective for testing the aging of indoor materials.​



2. Simulated Sunlight

Damage to material durability is primarily caused by the sun's ultraviolet rays, which produce very little energy in the visible or infrared spectrum. We can choose UV lamps with different wavelengths according to different test requirements, because the total energy and wavelength of UV radiation in each lamp tube are different. Generally, UV lamps can be divided into two types: UVA and UVB





Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test 0

Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test 1

Laboratory Programmable UV Light Test Chamber For Plastic Paint Rubber Test 2

UV Accelerated Aging Testing MachineHZ-2008.pdf
