408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius

408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius
408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius
408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius 408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius 408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius 408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius

Large Image :  408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius

Product Details:
Place of Origin: China
Brand Name: lixian
Certification: CE
Model Number: HZ-2019
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: wood
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: negotiate

408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius

Description
Temprature Range: -70oC To 150oC Inside Size: 40*50*40; 50*60*50; 50*75*60;60x85x80
Timer : 0.1 To 999.9 (S,M,H)adjustable Heating-up Time: -40oC To 100oC About 55min
Fluctuate/uniformly: ≤±0.5oC /.+2oC To 3oC Display: LCD
Humidity Range: 10~98%RH Humidity Resolution: 0.1%RH
Humidity Stability: ±2.0%RH Humidity Uniformity: ±3.0%RH
Power Supply: AC220V/50Hz Temperature Accuracy: ±0.5℃
Temperature Resolution: 0.1℃ Temperature Stability: ±0.5℃
Temperature Uniformity: ±2.0℃ Type: Environmental Testing Machine
High Light:

408L Temperature Test Chamber

,

Temperature Test Chamber For Electronic

,

Temperature 50Hz Test Chamber

408L High and Low Temperature Test Chamber for Electronic, Plastic Products, Electrical Appliance -70 to 150 Celsius

High and Low Temmperature Test Chamber summary:

Temperature test chamber can test the material property in high and low temperature, such as electrical, electronic products, as well as their original devices, The testing equipment is mainly made according to the national standard and user-defined requirements.



High and Low Temmperature Test Chamber Corresponding standard:

1.GB 10589-89 low temperature testing condition
2. GB 10592-89 high temperature testing condition
3. GB 11158-89 high temperature testing condition
4. GB/T5170.2-1996 basic parameters of environmental testing method for Electrical and electronic products,

High and Low Temmperature Test Chamber Applicable industries :

Applied to test the products quality, such as electronic, plastic products, electrical appliances, instruments, food, vehicles, metals, chemicals, building materials, aerospace, medical care.



High and Low Temmperature Test Chamber technical parameter:

Capacity 80L 150L 225L 408L 608L 800L 1000L
Inner size W×H x D cm 40*50*40 50*60*50 50*75*60 60x85x80 80x95x80 100x100x80 100x100x100
External size W×H x D cm 90x136x94 100x146x104 100x161x117 110x171x137 130x181x137 150x186x137 150x186x157
index temperature -70oC to 150oC
fluctuate/uniformly ≤±0.5oC /.+2oC to 3oC
Heating-up time -40oC to 100oC about 55min
Cooling time 25oC to -70oC about 80min
Control system controller LED digital P,I,D, +S,S,R.microcomputer controller
accuracy Setting accuracy temperature ±0.1oC,directed accuracy temperature ±0.1oC,resolution ±0.1oC
sensor Platinum resistance PT100Ω/MV
Heating system Independent system, nickel-chromium alloy electric heating type heater
Cooling system Totally enclosed air-cooled single-stage compression refrigerate mode / original from French "Taikang" / totally enclosed air-cooled re-compression refrigerate mode
Circulatory system Temperature, low-noise, air-conditioning-type motor. Multi-vane centrifugal wind wheel







408L High And Low Temperature Test Chamber 50Hz For Electronic -70 To 150 Celsius 0



High and low temperature test machine-2 HZ-2019.pd...
