Computer Rubber Mooney Viscometer RT200C Rotor Speed 2 Rotation/Min ISO 6502: 1991
Rubber Mooney Viscometer HZ-7001B New.pdf
Mooney Viscometer Equipment Summary
HZ-7001B Mooney Viscometer viscosity for rubber vulcanization index determination. Sample in a certain temperature and pressure, the rotor to a certain degree of rotation torque on the sample to a certain degree of shear stress, measure out the rubber anti-shear torque. Is reclaimed rubber, rubber, wire and cable industry indispensable instrument.
Mooney Viscometer Meet the Standards
1)HG / T 3242 rubber Mooney viscometer technical conditions
Rubber - Determination of vulcanizability using a rotorless vulcanizing apparatus
2)ISO 6502: 1991 (E) Rubber - Determination of vulcanizability using a rotorless vulcanizer
3)ISO 289-1 (1994) Unvulcanized rubber - Determination with a shear disc viscometer
Applicable Industry
Widely used in the measurement of quality inspection; rubber research; automotive manufacturing; wire and cable; medical equipment; civil aviation; institutions of higher learning; research laboratories; technical supervision departments; petrochemical; tire production; other industries.
Mooney Viscometer Technical Parameter
| Model |
HZ-7001B |
| Control temperature range |
room temperature~200℃ |
| Temperature display resolution |
0.01℃(0.1 ℃ common type of imported temperature controller) |
| Temperature control accuracy |
± 0.3℃ |
| Calibration accuracy |
Mooney value ± 0.5 |
| Rotor speed |
2 rotation/ min ± 0.02rotation / min |
| Torque range |
Mooney value 0～200 |
| Torque resolution |
Mooney value 0.1 |
| Print content |
Date, time, temperature, Mooney scorch curve |
| Power |
50HZ, 220V |
Mooney Viscometer Features
● Test Standard Modular Function: Provides the user to set the required test settings, covering GB, ASTM, DIN, JIS,BS ... and other test standards.
● test information: provide users to set all the test data, a permanent importation.
● Graph Curve Scale Auto Scale, allows the graph to be displayed at the best scale. And real-time graphics in the test dynamic Switch.
● Temperature control circuit by the monitoring module, platinum resistance, heater composition, can automatically track changes in power grid and ambient temperature, PID parameters automatically amend,to achieve rapid, precise temperature control purposes.
● Computer control and interface board for data collection, preservation, processing and printing of test results and curves.
● Software platform can be Window 98 / me / NT / XP and other versions of the visual graphics software window user interface to make digital processing more accurate operation,more simple, flexible and convenient.
