Product Details:
Place of Origin: China
Brand Name: lixian
Certification: CE
Model Number: HZ-2019
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: wood
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: negotiate

-70C to 150C High And Low Temperature Testing Machine 80L 150L HZ-2019

Description
Model: HZ-2019 Inside Size: 40*50*40; 50*60*50; 50*75*60;60x85x80
Temprature Range: -70oC To 150oC Meet Standards: GB 10589-89;GB 10592-89;GB/T5170.2-1996
Fluctuate/uniformly: ≤±0.5oC /.+2oC To 3oC Heating-up Time: -40oC To 100oC About 55min
Cooling Time: 25oC To -70oC About 80min Service: OEM\ODM
Timer : 0.1 To 999.9 (S,M,H)adjustable Voltage: Voltage
High Light:

ODM Temperature Testing Machine

,

80L Temperature Testing Machine

,

150L Environmental Testing Machine

High And Low Temperature Testing Machine 80L, 150L, -70℃ To 150℃ HZ-2019

High and Low Temmperature Test Equipment Equipment summary:

Temperature test chamber can test the material property in high and low temperature, such as electrical, electronic products, as well as their original devices, The testing equipment is mainly made according to the national standard and user-defined requirements, it simulate the environment to test proformance of material as well as other relevant characteristics of physical at low temperature or high temperature, Through testing to determine product performance whether it is still be able to meet the intended requirements.



High and Low Temmperature Test Equipment Corresponding standard:

1.GB 10589-89 low temperature testing condition
2. GB 10592-89 high temperature testing condition
3. GB 11158-89 high temperature testing condition
4. GB/T5170.2-1996 basic parameters of environmental testing method for Electrical and electronic products,
5. GB2423.1-89 The basic test regulation for electrical and electronic products, Test A: low-temperature test method
6. GB2423.2-89 The basic test regulation for electrical and electronic products, Test B: high-temperature test method


High And Low Temperature Testing Machine​ Applicable industries :

Applied to test the products quality, such as electronic, plastic products, electrical appliances, instruments, food, vehicles, metals, chemicals, building materials, aerospace, medical care.



High And Low Temperature Testing Machine technical parameter:

Capacity 80L 150L 225L 408L 608L 800L 1000L
Inner size W×H x D cm 40*50*40 50*60*50 50*75*60 60x85x80 80x95x80 100x100x80 100x100x100
External size W×H x D cm 90x136x94 100x146x104 100x161x117 110x171x137 130x181x137 150x186x137 150x186x157
index temperature -70oC to 150oC
fluctuate/uniformly ≤±0.5oC /.+2oC to 3oC
Heating-up time -40oC to 100oC about 55min
Cooling time 25oC to -70oC about 80min
Control system controller LED digital P,I,D, +S,S,R.microcomputer controller
accuracy Setting accuracy temperature ±0.1oC,directed accuracy temperature ±0.1oC,resolution ±0.1oC
sensor Platinum resistance PT100Ω/MV
Heating system Independent system, nickel-chromium alloy electric heating type heater
Cooling system Totally enclosed air-cooled single-stage compression refrigerate mode / original from French "Taikang" / totally enclosed air-cooled re-compression refrigerate mode
Circulatory system Temperature, low-noise, air-conditioning-type motor. Multi-vane centrifugal wind wheel
material Outer material High-quality carbon steel plate. Phosphide electrostatic spray treatment / SUS304 stainless steel hairline treatment
Inside material SUS304 High-quality stainless steel light board
Insulation material Rigid polyurethane foam, ultra-fine glass fiber cotton
insulation Double-resistant high-temperature aging of silicone rubber seal
Standard collocation a set of Multi-heated glass window attached lighting, testing product shelf 2 pcs, test leads holes (25,50 mm) 1 pcs
Protector Leak current, short circuit, over temperature, motor overheating, over-pressure compressor, overload, over-current protection
Timer 0.1 to 999.9 (S,M,H)adjustable
Voltage AC380V±10%, 50±0.5Hz Three-phase five-wire system
environmental temperature 5oC to 30oC ≤85%R.H
