Footwear Static Anti Slip Testing Machine Meeting Standard ISO 13287 2007 Computer Control + Special Software

Large Image : Footwear Static Anti Slip Testing Machine Meeting Standard ISO 13287 2007 Computer Control + Special Software

Product Details:

Place of Origin:	CHINA
Brand Name:	lixian
Certification:	CE
Model Number:	HZ-3634

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiate
Packaging Details:	wooden
Delivery Time:	7days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	5 hundred sets per month

Contact Now

Footwear Static Anti Slip Testing Machine Meeting Standard ISO 13287 2007 Computer Control + Special Software

Description

Model:	HZ-3643	Standard:	ISO 13287:2007
Max Vertical And Horizontal:	1000N	Minimum Speed:	(0.3±0.03)M/S
Static Time:	0-5S	Vertical Sensor:	2KN
Control Method:	Computer Control + Special Software	Power:	AC220V
Wedge Angle Gauge:	7°	Machine Dimensions:	2000mm * 700mm * 1250mm (length * Width * Height)
Highlight:	Footwear Static Anti Slip Testing Machine , Computer Control Anti Slip Testing Machine , Special Software Anti Slip Testing Machine

Footwear Static Anti-slip Testing Machine meeting standard ISO 13287:2007 computer control + special software

Footwear Static Anti-slip Testing Machine Equipment description:

Footwear static anti-slip testing machine developed based on extensive biomechanical research, it represents the conditions encountered during walking may occur slipping. This non-slip machine consists of a specially designed control instrument and data collection systems, for provide users with the coefficient of friction for each test sample. This is obtained through close control of the force involved in testing, including the variable speed motor provides velocity. The controller on the instrument and its unique circuitry designed to ensure that the testing process can maintain the proper force and velocity.

Main functions:

Footwear static anti-slip testing machine used to each test machine testing standards, instrument calibration, and the floor test interface. Other test interface also applies to this instrument, as long as the size suitable for installation in the instrument, almost all types of test interfaces can be used footwear static anti-slip testing machine for testing. Its unique design makes this instrument can be used to measure shoes and standard floor interface between the non-slip coefficient can also be used to measure anti-slip coefficient between a variety of floor interface with standard substrate.

Applicable industry:

Footwear with outer soles, the end of shoe heel or outside the test of the static non-slip performance.

Meet the standards: ISO 13287:2007 / SATRA TM144 / EN ISO 13287 /ASTM F2913

Footwear Static Anti-slip Testing Machine Technical Parameters

Model	HZ-3643
Standard	ISO 13287:2007
max vertical and horizontal	1000N
minimum speed	(0.3±0.03)M/S
static time	0-5S
vertical sensor	2KN
Control method	computer control + special software
Power	AC220V, 50Hz, 0.75KW
wedge angle gauge	7°
Machine dimensions	2000mm * 700mm * 1250mm (length * width * height)

Footwear Static Anti Slip Testing Machine Meeting Standard ISO 13287 2007 Computer Control + Special Software 0

Footwear Static Anti Slip Testing Machine Meeting Standard ISO 13287 2007 Computer Control + Special Software 1

Footwear Static Anti Slip Testing Machine Meeting Standard ISO 13287 2007 Computer Control + Special Software 2
